Clarke Vantage 14 Original Instruction

ENGLISH
10
Instructions For Use - VANTAGE 14
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER –
WARNING –
CAUTION –
CONSULTATION –
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately replace them if damaged.
BATTERY CHECK/SETTING ON A NEW MACHINE
WARNING!
The electric components of the machine can be seriously damaged if the battery is either improperly installed
or connected. The battery must be installed by qualied personnel only. Check the battery for damage before
installation.
Disconnect the battery connector and the battery charger plug.
Handle the battery with great care.
Install the battery terminal protection caps supplied with the machine.
The machine requires 1 12V battery.
The machine is supplied in the following conguration:
GEL/AGM battery already installed on the machine
Open the cover (4) and check that the battery is connected to the machine with the connector (7).1.
Start the machine (see Machine Start and Stop paragraph). If the green warning light (38) turns on, the batteries are ready to 2.
be used.
If the yellow or red warning light turns on, the battery must be charged (see the procedure in Maintenance chapter).3.
Without battery
Buy appropriate battery (see the Technical Data paragraph).1.
For battery choice and installation, apply to qualied battery Retailers.
Install the battery (see the following paragraph).2.
Charge the battery.3.
BATTERY INSTALLATION
Open the cover (4) and check that the battery connector (7) is disconnected.1.
Install the battery on the machine and fasten it with the relevant bracket.2.
DANGER!
This machine requires sealed lead batteries (GEL or AGM technology).
Do not use batteries with liquid electrolyte or not sealed (WET) for any reason.
WARNING!
The installed battery (GEL/AGM) may require a specic charging algorithm: contact a Clarke Service Center to
set the charging algorithm suitable to the battery.
Battery charging
Charge the battery (see the procedure in Maintenance chapter).3.
A1 ENGLISH.indd 10 03/08/2011 14.54.47
