GENERAL VIEW
Kit Ref. Part No. Description Qty
K2
1
NUT, HEX NYL LOC THIN M6 SS 2
K2
2
NUT, HEX NYL LOC THIN M5 SS 3
3 -
BRUSH HUB DX ASSY 1
4 L08812203
KNOB 2
5 L08812426
CAP 2
K2
6
WASHER, FLAT XL RUBBER 2
K2
7
WASHER, FLAT XL 9.5x27x2.5 4
K2
8
SCREW, HEX THD TO HD M8x20 SS 1
K2
9
VITI TCEI/SCR, SOC HD 4
K2
10
WASHER, FLAT 6,4x12,5 S.S. 4
K2
11
WASHER, FLAT XL 5,5x15 SS 1
K2
12
WASHER, EXT. SHPRF Ø 6 SS 4
K2
13
SCREW, HEX THD TO HD M6x20 SS 2
K2
14
NUT, HEX NYL LOC THIN M8 SS 1
K2
15
WASHER, FLAT XL SS 1
K2
16
TIE, CABLE 4,8X200 4
K2
17
TIE, CABLE 2,9X130 2
K2
18
WASHER, FLAT 5.3x10x1 SS 2
19 1464853000
BATTERY DISCOVER 12V 84Ah (BAT) 1
K2
20
CLAMP, HOSE d.18 1
21 -
BRUSH DECK SUPPORT ASSY 1
22 9098394000
FLANGE 1
23 9098529000
BRUSH PROLENE DIAM. 370 mm 1
23*
9099006000 BRUSH D.370 PROLITE PPL 1
23*
9099007000 BRUSH D.370 UNION MIX 1
23*
9099008000 BRUSHD.370MIDGRIT240 1
23*
9099009000 BRUSH D.370 MIDLITE GRIT 1
[24]*
9099010000 PAD HOLDER D.350MM 1
[24]*
L00190797 PAD14355MMBROWN5PCS 1
[24]*
L00190798 PAD14355MMRED5PCS 1
[24]*
L00190799 PAD14355MMWHITE5PCS 1
[24]*
L00306400 PAD14355MMGREEN5PCS 1
25 9098589000
SQUEEGEE HOSE 1
K2
26
SCREW, FLAT SOCKET HEAD 1
K2
27
NUT, HEX THIN M5 SS 1
K2
28
CLAMP. HOSE 8/24-36 SS 2
K1
29
ADJUSTEMNT BRUSH DECAL 1
K1
30
REGULATION BALANCING MACHINE DECAL 1
31 9099042000
DECK CABLE 2
32 -
BATTERY COVER ASSY 1
33 -
TANK BLU ALTO ASSY 1
34 -
FRAME ASSY 1
35 -
TANK COVER ASSY 1
36 9099112000
PANEL BATTERY 110X170X10 1
37 -
HANDLE BAR - ALTO VERSION ASSY 1
K1 38
DECAL, CLARKE VANTAGE 14 2
K2
39
SCREW, BUTTON SOC M8X55 1
K2
40
SCREW, BUTTON SOC M 10X25 SS 2
41
COVER DECK CLARKE ASSY 1
42 145 8024 000
KEY 5X5X25 1
43 9098557000
PIN, BRUSH PLATE FIXING 2
44 9096914000
CABLE EXTENSION US 1
[K1] 9099306000 DECAL KIT VANTAGE 14 1
[K2] 9099301000 GENERAL VIEW WH KIT 1
