Clarke Vantage 14 Original Instruction

Parts List - Vantage14
59
COVERANDTANKS
Kit Ref. Part No. Description Qty
K1 1 FLOAT, BALL 1
K1 2 CAGE FLOAT 1
K1 3 SCR,PAN PHIL THD FORM 6
K1 4 9098319000 GASKET 1
K1 5 COVER TANK 1
K1 6 CAP TANK COVER 1
K1 7 9099077000 GASKET 1
K1 8 GASKET MOUSSE D.4MM 1
K2
9
WASHER, EXT. SHPRF Ø 6 SS 6
10
146 2449 000 JOINT 1
K2 11 THREAD ROLLING SCR 5X16 6
12 9098309000 PLATE 1
K2 13 BUSH 2
14 9099079000 BATTERY COVER 1
15 9099088000 DIRTY WATER TANK
1
K2 16 WASHER, FLAT 6,4X12,5 S.S. 4
K2
17
THREAD ROLLING SCR 6X30 4
K2
18
WASHER, FLAT 4,3x9 4
K2
19
PAN HEAD SCREW (PLASTIC)
4
K2 20
PIN, SPRING 6x40 2
K2 21 SPACER 30X45X3 SS 2
22 9099155000 CAP THREADED 70X5 1
23 9099087000 FRESH WATER TANK 1
24 9099089000 HANDLE TANK 1
K1 9099302000 COVER KIT 1
[K2] 9099303000 WH COVER AND TANKS KIT 1
