FRAME
Kit Ref. Part No. Description Qty
K1 1 REDUCTION WATER 1
K2 2 WASHER 5X15 UNI6593 SS 4
K2 3 SCREW 3.5X10 THD FORMING 2
K2 4 NUT SELF L. M6 UNI7474 SS 3
K2 5 NUT SELFLOCKING LOW M5 UN 5
K2 6 WASHER 6X18 UNI6592 2
K2 7 SCREW M6X20 UNI5731 2
K2
8 WASHER 1
K2 9 SCREW M5X20 UNI5931 SS 4
K1 10 FITTING 1
K2 11 WASHER 2
K2 12 SCREW 2
13 9098237000 WHEEL D.200MM 2
14 9098144000 CHASSIS 1
15 9098188000 CHARGER BATTERY 12V 12A (CH) 1
16
9098319000 GASKET 1
17 146 3054 000 BELT BATTERY FIXING 1
K1 18 CLAMP 1
19
9098915000 TAPPO 2
20 9098697000 VALVE WATER COMPLETE 1
K2 21 SCREW 1
K1 22 HOSE D.12 L=500 MM 1
K2 23 RING D 12 UNI7435 4
K2
24
WASHER 12.5X34X3 NYLON 2
25 9098310000 PIN WHEEL 1
K1 26
HOSE D. 12 1
K1 27 PIPE 6X11 1
K2 28 CLAMP 290X4.8 1
K1 9098992000 PIPES KIT 1
[K2] 9098993000 HARDWARE FRAME KIT 1
