33A
146 0626 000 1 TELERUTTORE DOPPIO 12V 70A (ES1) SWITCH ELECTROMAGNETIC 12V (ES1)
vecchia versione inserire matricola
HANDLE SUPPORT
Kit Ref. Part No. Description Qty
1 9098760000 CONNECTOR 50A GREY 2
2 9098924000 FUSE HOLDER 2
K1 3 NUT SELFLOCKING LOW M8 UN 4
4 909 6542 000 GROMMET 2
K1 5 SCREW M3X16 UNI7687 2
K1 6 SCREW 3.5X10 THD FORMING 3
K1 7 WASHER M8 UNI6592 SS 4
K1
8
NUT SELF L. M6 UNI7474 SS 6
K1 9 SCREW M8X20 UNI5739 SS 4
K1 10 WASHER M6 UNI6592 SS 8
K1 11 SCREW 2
K1 12 WASHER 2
K1 13 SCREW 2
K1 14 WASHER 6
K1 15 SCREW 2
16
909 5706 000 BREAKER CIRCUIT 30A (F1) 1
K1
17 SCREW M5X10 DIN7500 5
18 9098111000 MOTOR VACUUM 12V 200W (M2) 1
19
9098112000 SOLENOID VALVE 12V (EV) 1
20 9099073000 BRACKET HANDLE 2
21 9098267000 SUPPORT HANDLE 1
22 9098268000 SUPPORT VACUUM MOTOR 1
23 9098319000 GASKET 1
24
9098327000 GASKET VACUUM MOTOR 1
25 9098365000 COVER RELAY 1
26
9098482000 BRACKET PLUNGER BLOCK 1
27 9099074000 COVER VACUUM MOTOR 1
28 9098554000 GASKET VACUUM MOTOR 1
29 9098654000 PROTECTION 1
30 9098655000 FILTER VACUUM MOTOR 1
K1 31 SPACER M4 L10 2
K1
32
SCREW M4X 8 UNI5739 SS
2
33
9098424000 SWITCH ELECTROMAGNETIC 12V 70A (ES1) 1
34 9098560000 PLATE SUPPORT ELECTR.SWITCH 1
K1 35 SCREW M6X12 UNI5931 SS 2
K1
36
WASHER 3
37 9098559000 SPACER SUPPORT VACUUM MOTOR 1
38 9098656000 CASING VACUUM MOTOR 1
39 9098925000 CASING LOWER VACUUM MOTOR 1
K1 40 SCREW M8X55 UNI5739 1
K1
41 NUT SELFLOCKING LOW M8 UN 1
K1 42 SCREW M10X25 UNI5739 SS 2
K1
43
CLAMP 2
K1 44 CLAMP 4
K1
45
SCREW SOCKET HD M6X16 SS 2
K1 46 WASHER M6 UNI6592 SS 4
K1 47 NUT SELF L. M6 UNI7474 SS 2
48 9098441000 RELAY 12V (ES2) 1
49 9098375000 TIMER CYCLICAL (T1) 1
50
145 8513 000
FUSE BLADE 30A UL (F2) 1
51
145 9852 000
FUSE 5A (F3) 1
52 9098387000 HARNESS MACHINE 1
53 9098849000 HARNESS BATTERY 1
[K1]
9098994000 HARDWARE HANDLE BAR SUPP. KIT 1
