HANDLE BAR
Kit Ref. Part No. Description Qty
K3 1 WASHER 3
2 L08603153 SWITCH PUMP (SW3) 1
3 L08603154 CAP PROTECTION 1
K5 4 WASHER 6X18X1.5 UNI6593 2
K5 5 SCREW M3X8 UNI7688 2
K5 6 CLAMP 290X4.8 1
K5 7 WASHER 2
K5 8
CLAMP 2
K5 9 SCREW 3.9X9.5 UNI6955 2
K5 10 INSERT M6X15 UNI9203 2
11 146 3073 000 BOARD. LED (EB1) 1
K5 12 SCREW M6X16 UNI7687 SS 2
13 909 5149 000 SUPPORT CABLE 1
14 9097283000 KNOB CONTROL FUNCTIONS 1
K5 15 SCREW GRUB M3X3 DIN916 1
K5 16
SCREW 2.9X25 UNI6954 THD 2
K5 17 SEAL O-RING 1
18 9098386000 HARNESS HANDLE BAR 1
19
9098405000 SWITCH ROTATIVE 4 POSITIONS (SW1) 1
20 9099129000 COVER HANDLE FRONT 1
21 9099242000 DECAL CONTROL PANEL 1
22 9098616000 DECAL BATTERY LED 1
23 9098812000 CAP FOR HANDLE 1
24
9098813000 CAP D.18.5/D.40MM BLACK 1
25 9098835000 TUBE HANDLE 1
26 9098836000 ROD INDEX 1
K4 27
LEVER SWITCH 2
K4 28 LEVER 1
K1 29 CAP RUBBER 1
K1 30 COVER REAR 1
K1 31 COVER FRONT 1
K4
32
BUTTON INTERLOCK 1
33 VF47033 RETAINER 1
34 30834A REAR COVER HANDLE 1
35 40263A SWITCH DPDT (SW2) 1
K4
36
SPRING INTERLOCK BUTTON 1
37
VF47007 SPRING COMPRESSION 1
K2
38 GEAR 1
39 60408A HOUSING GEAR INDEX 1
K4 40
CLAMP CORD 1
K4 41
PIN HANDLE SUPPORT 4
K2 42 GEAR INDEX 1
K3 43 HANDLE SUPPORT 1
K2 44 PLATE, GEAR HOUSING 2
K4 45 SCREW M3X25 2
K1 46
SCREW ST4.2-1.4 4
K3 47
SCREW M5X43 1
K3 48 NUT LOCK M5 SS HEX 1
K4 49 NUT LOCK M4 SS HEX 1
50 VF14506 NUT LOCK M6 SS HEX 4
K3 51 SCREW M5X40 SS PAN HEAD PHILLIPS 1
K2-K5 52
SCREW M4X8 UNI7688 2
K4 53 SCREW M4X10 SS PAN HEAD PHILLIPS 3
K3 54 SCREW M5X12 TRUSS HEAD PHILLIPS 6
55 GT13019 SCREW M6X40 SS HEX HEAD 4
56
80398A SCREW M5x35 SS HEAD PHILLIPS 2
57
80402A NUT LOCK M6 SS HEX 1
58
80407A SCREW M5X25 SS FLAT HEAD PHILLIPS 4
K1
11271A LOWER COVER KIT 1
K2
56381560 BOX HOUSING GEARS KIT 1
K3
11273A HANDLE SUPPORT KIT 1
K4
11274A HANDLE SWITCH LEVER KIT 1
K5
9098995000 HARDWARE HANDLE BAR KIT 1
