Clarke Vantage 14 Original Instruction

Parts List - Vantage14
67
BRUSHDECK
Kit Ref. Part No. Description Qty
K2 1 NUT SELF L. M6 UNI7474 SS 4
2 L08812213 BUFFER 2
3
L08812779 PLATE.VIBRATION DAMPING 2
K2 4 NUT SELF L. M8 UNI7473 1
K2 5 SCREW M6X35 UNI5931 SS 4
K2 6 WASHER 1
7 9097184000 VIBRATION DAMPING M8 60SH 1
8 9098083000 SUPPORT BRUSH DECK 1
K2 9
SCREW M8X12 UNI5739 SS 1
10 L08601624 HOLDER RUBBER 1/4 D.10 1
K2 11 SCREW M6X25 UNI5931 SS 8
K2 12 WASHER 4
13 9097976000 REDUCTION GEARMOTOR 12V (M1) 1
14 L08812306 HUB.BRUSH R.GEARMOTOR 1
15 L08812480 HUB.BRUSH 1
K2 16 SCREW M6X20 UNI5931 SS 3
K1 17 SPRING RING DIAM. 50 3
K1 18 SPRING RING DIAM. 78 1
K2 19
WASHER NORD LOCK M6 3
K1
9098991000 RINGS SPRING KIT 1
[K2]
9098996000 HARDWARE DECK KIT 1
