BRUSHDECK
Kit Ref. Part No. Description Qty
1 9098475000 BRUSH LINEAR 1
2 L08603027 ROLLER BUMPER 1
K3 3 SCREW 3.9X13 UNI6954 1
4 L08603402 ROLLER 2
K1 5 NUT HEX SELFLOCK M6 SS 13
K3 6 NUT SELF L. M5 UNI7474 1
K3 7 WASHER 4X12 UNI6592 SS 1
K1
8
WASHER 3
K3 9 PIN 1
K1 10 NUT M10X1.5 UNI7473 3
K3 11 WASHER 5X15 UNI6593 SS 2
K1 12 SCREW M6X16 UNI7687 SS 13
K3 13 NUT SELF L. M10 UNI7474 3
14 9099163000 WHEEL CASTOR D.42 3
K2 15 SQUEEGEE BODY 455MM/18 1
K2 16
STRAP REAR SQUEEGEE 455MM 1
17 9099160000 COVER BRUSH DECK BLACK 1
K1 18 FLANGE 132X100X2 2
K1 19
COUPLING RUBBER DECK 1
K1 20 FLANGE 195X165X2 1
21 9098473000 COVER PIN 2
22 9098477000 COUNTERWEIGHT 1
K2 23 9099027000 BLADES SQUEEGEE KIT 1
K2
24
STRAP FRONT SQUEEGEE 455 1
K3 25 NUT HEX M5 UNI5589 SS 2
K1 26
VIBRATION DAMPING M6 D.20X10 3
27 9098633000 PLATE BUMPER FIX 2
K3 28 SCREW M5X30 UNI5933 SS 1
K3 29 WASHER M10 UNI8842A SS 2
K3 30 SCREW M5X20 UNI5933 SS 1
K1
9098997000 COUPLING DECK KIT 1
K2
9098998000 SQUEEGEE KIT 1
[K3]
9098999000 HARDWARE COVER DECK KIT 1
