WIRING DIAGRAM
Key. Part No. Description
BAT 1464853000
BATTERY DISCOVER 12V 84Ah
CH 9098188000
BATTERY CHARGER
D1 -
DIODE
D2 -
DIODE
EB1 146 3073 000
BATTERY CHARGER LEVEL BOARD
ES1 9098424000
BRUSH MOTOR CONTACTOR
ES2 9098441000
VACUUM MOTOR RELEAY
EV 9098112000
DETERGENT SOLENOID VALVE
F1 909 5706 000 BRUSH CIRCUIT BREAKER
F2 145 8513 000 VACUUM FUSE (30 A)
F3 145 9852 000 ROTATIVE SWITCH FUSE (5 A)
M1 9097976000 BRUSH MOTOR
M2 9098111000 VACUUM MOTOR
SW1 9098405000
ROTATIVE SWITCH
SW2 40263A
SWITCH M1-EV
SW3 L08603153 DETERGENT SWITCH
T1
9098375000
SOLENOID VALVE TIMER
BK BLACK BLACK
BU LIGHT BLUE LIGHT BLUE
BN BROWN BROWN
GN GREEN GREEN
GY GREY GREY
OG ORANGE ORANGE
PK
PINK PINK
RD
RED RED
VT
VIOLET VIOLET
WH
WHITE WHITE
YE YELLOW YELLOW
