SB-704 MAIN STATION
1-11
Note: To “latch” (or “lock”) a button to “on,” quickly press it once. The
button is “locked” to “on” for hands-free use. Pressing the button
again releases the latch. Otherwise when you press and hold a button
the feature switches on, and when you release the button the feature
switches off. This is called “momentary” use.
All-Talk Key (press to send
microphone’s audio to all
channels)
Amber Off Momentary only
Link-On Key (press to link all
channels together so that station
operates as one party line)
Amber Off Latching only
Remote Microphone Kill Key
(press to clear all latched talks
on connected remote
stations/beltpacks on all
channels)
Amber Off Momentary only
Short/Overload Light (lights
when there is a short or overload
on the associated channel)
Red Off Neither
Mic Select Switch (to select to
activate either the panel or
headset microphone)
n/a n/a n/a
Speaker On/Off Switch (to
switch station speaker on or off)
n/a n/a n/a
Volume Knob (adjusts overall
incoming volume on all
channels)
n/a n/a n/a
Listen Level Knob (adjusts
incoming volume to selected
channel only)
n/a n/a n/a
Channel Slide Switch (assigns
each of 10 individual stations to
one of four channels)
n/a n/a n/a
Channel Light (shows if there is
a call signal on a channel)
amber off n/a
Function (Continued) “On” State “Off” State Momentary or Latching
