Quick-Start Guide
8QSG-0081-002v1.0 January 2021
Connect the Components
Description of Controls and Connections
Huddle CTH
a Expander port: RJ45 connector
b Ethernet/PoE; RJ45 connector.
PoE Injector
c
RJ45 connector. Used to provide power to Huddle CTH.
d RJ45 connector. Not used.
Figure 1. Huddle CTH Backplane
Figure 2. PoE Connections
