ClearView PhoenixPlus-08-M - Connection Sample

20
In motion detection interface,
working with direction keys to
complete setup.
In text mode, click it to delete
character.
15
0-9 number key
Input password, channel or
switch channel.
Shift is the button to switch the
input method.
2.7 Connection Sample
Please refer to Figure 2-13 for connection sample. The following figure for reference only.
Figure 2-13
