Section 2 — Installation
2-10 Part No. 750-263
27.Attach front skirt panel to the side panels.
28.Install front panel.
Assembly is now complete.
B. FLUE GAS / COMBUSTION AIR CONNECTIONS
The flue gases from the Model CFC boiler should be removed via a
gas-tight, temperature and corrosion resistant flue gas pipeline.
Only flue gas systems approved and tested by the relevant region or
province are to be connected to the boiler. Refer to flue piping
Figure 2-17
Figure 2-18
