CB FALCON MODBUS COMMUNICATION
26
Table 4. CB Falcon Modbus register map
0261 0609 S2 (J8-6) connector type(4-
20mA remote control input)
R/W U16
SAFETY parameter
f
:
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0262 0610
S3S4 (J8-8, 10) connector
type
(Outlet dual sensor)
(Outlet limit sensor and
Outlet operation sensor)
R/W U16
SAFETY parameter
f
:
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0263 0611 S5 (J8-11) connector type R/W U16
SAFETY parameter
f
:
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0264 0612 S6S7 (J9-1, 3)
connector type
(DHW dual sensor)
(DHW limit sensor and DHW
operation sensor)
R/W U16
SAFETY parameter
f
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0265 0613
S8S9 (J9-4, 6)
connector type
(Stack dual sensor)
(Stack limit sensor and
Stack operation sensor)
(Stack limit sensor and
Heat exchanger sensor)
R/W U16
SAFETY parameter
f
:
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0266 0614 S10 (J10-7) connector type R/W U16
SAFETY parameter
f
:
0=Unconfigured,
1=Raw A2D counts,
2=10K NTC dual temperature,
3=10K NTC single temperature,
4=12K NTC single temperature,
5=0-15 psi pressure,
6 =0-150 psi pressure,
7=4-20 mA
0267-026F 0615-0623 RESERVED
EXTENDED SYSTEM
CONFIGURATION
0270 0624 Installer passcode W U16
To set new installer passcode (000-999). Requires
register access status (register 177) set to Installer or
higher.
0271 0625 OEM passcode W U16
To set new OEM passcode (000-999). Requires register
access status (register 177) set to OEM or higher.
