CleaverBrooks CFC-E Series User Manual

BOILER BOOK CFC-E DIMENSIONS AND RATINGS
10
Table 1. U.S. Standard Dimensions Model CFC-E Boiler
ITEM DIMENSIONS (inches) 500 750 1000 1500 2000
A Overall Height 78.0 78.0 78.0 79.9 79.9
B Overall Width 34.9 34.9 34.9 35.8 35.8
C Overall Depth 49.4 49.4 49.4 56 56
D Width Less Casing 32.1 32.1 32.1 33.0 33.0
E Gas Connection to Floor 70.3 70.3 70.3 73.9 73.9
F Side of Casing to Gas Connection 3.7 3.7 3.7 7.1 7.1
G Side of Casing to Air Inlet 10.8 10.8 10.8 10.8 10.8
H Top of Casing to Air Inlet 7.7 7.7 7.7 7.1 7.1
J Floor to Condensate Drain 6.3 6.3 6.3 6.3 6.3
K Floor to Bottom of Casing 11.0 11.0 11.0 11.0 11.0
L Side of Base to Flue Outlet (Centered) 7.4 7.4 7.4 8.5 8.5
M Side of Base to Flue Outlet (Offset) 6.4 6.4 6.4 7.5 7.5
N Rear of Base to Flue Outlet 6.5 6.5 6.5 7.5 7.5
P Casing Depth 36.3 36.3 36.3 42.4 42.4
Q Casing Height 67.0 67.0 67.0 68.9 68.9
R Floor to Lower Return Connection 16.8 16.8 16.8 16.8 16.8
S Floor to Upper Return Connection 31.8 31.8 31.8 31.8 31.8
T Floor to Supply Connection 59.5 59.5 59.5 59.5 59.5
U Floor to Air vent Connection 66.3 66.3 66.3 66.3 66.3
V Air Vent Line Projection From Rear of Casing 3.2 3.2 3.2 3.3 3.3
CONNECTIONS
W Water Low Temp. Return, Class150 RF Flange 2-1/2" 2-1/2" 2-1/2" 4" 4"
X Water High Temp. Return, Class150 RF Flange 2-1/2" 2-1/2" 2-1/2" 4" 4"
Y Water Outlet, Class150 RF Flange 2-1/2" 2-1/2" 2-1/2" 4" 4"
Z Air Vent, NPT 1-1/2" 1-1/2" 1-1/2" 1-1/2" 1-1/2"
AA Vessel Drain, NPT 1-1/2" 1-1/2" 1-1/2" 1-1/2" 1-1/2"
BB Flue Gas Outlet
(Standard) - Nominal 6" 6" 8" 8" 8"
(Option) - Nominal 8" 8" 6" 10" 10"
CC Combustion Air - Nominal 6" 6" 6" 8" 8"
DD Gas, NPT 1" 1" 1" 1-1/2" 1-1/2"
EE Condensate Drain, NPT 1" 1" 1" 1" 1"
FF Electrical Opening, Left or Right 1.6" 1.6" 1.6" 1.6" 1.6"
GG Safety Relief Valve Vessel Connection, NPT 1-1/4" 1-1/4" 1-1/4" 1-1/4" 1-1/4"
HH Safety Relief Valve
30 psig Inlet x Outlet, NPT 1" x 1-1/4" 1" x 1-1/4" 1" x 1-1/4" 1" x 1-1/4" 1-1/4" x 1-1/2"
50 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 1" x 1-1/4"
60 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 1" x 1-1/4"
75 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1"
80 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1"
100 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1"
125 psig Inlet x Outlet, NPT 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1" 3/4" x 1"
JJ Flue Coupling, NPT 3/4" 3/4" 3/4" 3/4" 3/4"
KK Water Outlet Coupling, NPT 1-1/4" 1-1/4" 1-1/4" 1-1/4" 1-1/4"
FORK POCKETS (inches)
LL Pocket Height 3.9 3.9 3.9 3.9 3.9
MM Pocket Width 11.8 11.8 11.8 11.8 11.8
NN Overall Pocket Width 27.6 27.6 27.6 27.6 27.6
WEIGHTS
Dry Weight (lb) 1298 1298 1396 1861 2041
Shipping Weight (lb) 1413 1413 1511 1986 2166
Operating Weight (lb) 2065 2065 2113 2778 2858
Water Volume (gallon) 92 92 86 110 98
CLEARANCES
Top 14"
Notes:
• Boiler rear must be accessible for servicing.
• Side clearance to wall or between boilers.
• Side clearance typical each side.
Side 3"
Rear 20"
Front 36"
