Connections
mPro400GCD-S, mPro400GCD-SH
Abb. 8-1: Connection positions
mPro400GCD-SH shown
X21
X23
X22
X26
X24
X25
(only on mPro400GCD-SH)
No.
Designation
No.
Designation
X21
System Bus Connector TSnet Out
X24
T
ool Connector Serie 30/50EAN
X22
System Bus Connector TSnet In
X25
T
ool Connector Serie 18/48EAE
X23
Power supply connection
X26
Ethernet RJ45 10/100 BASE-T Connector
35
37
