Apex Tool Group P2349HW | 2019-08 9
1
EN
3 Product description
Controller for use in safety-critical tightening.
The controller is primarily used as a control and monitoring
unit for one or more tools at a workstation. Depending on
the peripheral devices that are procured, the controller can
also be installed outside of the work environment.
Software is already installed on the controller. The tighten-
ing settings must be carried out by a qualified person using
the Primary-/Master-controller or remote PC software
(mProRemote) in order to start fastening work. For further
information regarding software operation, please reference
the Programming Manual mPro400GCD.
The secondary controller is an extension module to the pri-
mary/master controller and is needed to operate an addi-
tional corded tool.
4 Technical Specifications
Ambient Conditions
Power Supply
Normative references
For product-relevant EC Directives, as well as the stan-
dards complied with, see the EC Declaration of Conformity.
System Data
Weight
Features Data
Operation Site Indoors
Ambient Temperature 0...45 °C
1
1. Note the derating. See the System Handbook NeoTek
Storage Temperature -20...70 °C
Type of Cooling Convection (self-cooling)
Relative Humidity 10...90 %, No Condensa-
tion
Working Height Up to 3000 m
Above Sea Level
Protection Class
DIN EN 60529
IP42
Protection Class
DIN EN61140
(VDE 0140-1)
I
Degree of Contamination
EN 61010
2
Transient Overvoltage
EN 61010
CAT
Maximum Shock
DIN EN 60068-2-27
15 G
Maximum Vibration
DIN EN 60068-2-5
59.6–160 Hz: 2 G
Features Data
Supply Voltage,
Single Phase
100–240 VAC ± 10%
1
Rated Supply Current 1–2 A
Frequency 50/60 Hz
Peak Current 16 A
Rated Power 1600 VA max.
Idling 160 VA
1. When operating outside the allowable voltage limits,
the integrated power supply enters a protection mode
and switches off. This protection mode can be reset
by restarting the nutrunner controller.
Certificates
Issuing agency TÜV SÜD AG
Certificate No. U8 78313 0005
Tested in accordance
with
• UL 61010-1:2012/
R:2016-04
• CAN/CSA–C22.2
No.61010-1:2012/
U2:2016-04
Certificate No.
Tested in accordance
with
N8A 78313 0007
• EN 61010-1:2010
Certificate No. DE3-30943
Tested in accordance
with
• IEC 61010-1:2010
Features Data
System Functions Battery Buffered Real Time Clock, Buffer
Time: 20 Years (at 20 °C)
Display LC Display With Touchscreen,
7" TFT Liquid Crystal Display,
Resolution 800 x 480, Connection To
Panel & Touch Possible
Operating System Linux Operating System
1
, Bootable With-
out Mechanically Moving Drives, No UPS
Required
1. This product includes several open source software
packages, distributed under various open source
licenses. Additional information about the open source
packages and licenses can be found at http://soft-
ware.apextoolgroup.com/oss-legal/
HMI
(Human Machine
Interface)
Virtual Keyboard for Alphanumeric Inputs
Model Weight
lb kg
mPro400GCD-S
mPro400GCD-SH
28.2 12.8
Features Data
