When Using This Car Seat
in Forward-Facing Mode
• Child’s weight is between 20 and 65 lb
(9.1 and 29.5 kg), AND
• Child’s height is between 30 and 49 in.
(76 and 124 cm), AND
• Child is at least 1 year of age, AND
• The tops of the child’s ears MUST be
below the top of the car seat’s Headrest,
as shown in Figure 3. If the tops of the
child’s ears are above the top of this car
seat’s Headrest in the highest adjustment
position, your child is too large for this
car seat.
• The Shoulder Harness Straps must be
through Shoulder Harness Slots at or
above and closest to the child’s shoulders,
as shown in Figure 3a. If the child’s
shoulders are above the highest set of
Shoulder Harness Slots in the car seat’s
seat back, your child is too large for this
car seat.
Figure 3 Figure 3a
• If child weighs more than 48 lb (21.8 kg)
or the weight limit specified for LATCH use
in your vehicle owner’s manual this car
seat must be installed with:
– the vehicle belt and Top Tether; or
– the LATCH lower connectors, vehicle belt
and Top Tether
