Removing Rear-Facing
Car Seat Installed With LATCH
Step 1
Loosen Rear-Facing LATCH Belt by pressing
the adjuster button on each Rear-Facing
LATCH Belt adjuster and pulling out on Rear-
Facing LATCH Belt as shown in Figure 26.
• Pressing down in center of car seat to
reduce tension on Rear-Facing LATCH
Belt will make it easier to loosen lower
anchor belt.
Step 2
Remove Rear-Facing LATCH Push-on
Connectors from vehicle lower anchors.
• Press and hold red release button while
pulling Rear-Facing LATCH push-on
Connectors as shown in Figure 27.
• Repeat to remove Push-on Connector on
opposite side.
Figure 26
Figure 27
Step 3
Remove this car seat from vehicle.
Step 4
Remove Seat Cushion, See “Removing/
Installing Seat Cushion” on page 84.
Store the Rear-Facing LATCH Belt, see “Rear-
Facing LATCH Storage” on page 88.
Step 5
Install Seat Cushion, See “Removing/
Installing Seat Cushion” on page 84.
