Shoulder Harness Cover
Removal/Installation
The Shoulder Harness Covers included with
this seat are optional.
To Remove: Locate the hook and loop
fasteners on the Shoulder Harness Covers,
separate them as shown in Figure 111, and
pull Shoulder Harness Covers off from the
Shoulder Harness Straps.
To Install: Wrap Shoulder Harness Covers
around Shoulder Harness Straps with hook
and loop fasteners facing away from child’s
neck and push hook and loop fasteners
together as shown in Figure 112.
Figure 111
Figure 112
Installing/Removing
Rear-Facing Base
TO INSTALL REAR-FACING BASE
Step 1
Place the car seat on a clean, stable surface
with the inside of the seat facing down.
Step 2
Line the Rear-Facing Base Retention Hooks
up with the openings in the bottom of the
car seat, as shown in Figure 113. Insert the
Rear-Facing Base Retention Hooks into the
openings and slide the base down until you
hear the Rear-Facing Base Release Lever
“click” to lock the base on as shown in
Figure 114.
Step 3
Pull up on Rear-Facing Base to check that it is
locked in place.
Figure 113
Figure 114
