Clek FOONF - Removing Forward-Facing Car Seat Installed With LATCH

55
56
Figure 61
Figure 62 Figure 62a
Step 1
Loosen Top Tether by pressing adjuster
release button while pulling strap as shown
in Figure 61.
Step 2
Remove Tether Hook from vehicle
tether anchor.
• Pull in and hold retention spring on
hook, then remove hook from Rear-
Facing Tether Anchor as shown in
Figure 62 or Figure 62a.
Step 3
If using LATCH and vehicle belt, open
Shoulder Belt Lock-off and unbuckle vehicle
belt.
Removing Forward-Facing Car Seat
Installed With LATCH
Step 4
Pull Rigid LATCH Lower Connectors to the fully
extended position as shown in Figure 63.
• Pull and hold Rigid LATCH Adjustment
Handle.
• Grasp the seat and slide it out until it stops.
• Release Rigid LATCH Adjustment Handle.
Step 5
Pull the red Rigid LATCH Release Handles,
one at a time and pull the car seat forward to
remove each Rigid LATCH Connector from the
vehicle LATCH anchor as shown in Figure 64.
IMPORTANT: Rigid LATCH Connectors
CANNOT be released unless they are FULLY
extended.
NOTE: Moving the car seat slightly from front
to back or side to side may make it easier to
release the Rigid LATCH Connectors from the
vehicle LATCH anchors.
Step 6
Remove this car seat from vehicle.
Step 7
Store the Top Tether and Rigid LATCH Connectors,
see “Top Tether Storage” and “Forward-Facing
Rigid LATCH Storage” on page 90.
Figure 64
Figure 63
