Clemens Technologies CL861.000000 right User Manual

RADIUS SL PLUS 03.2019 en 45
10.12 Hydraulic hoses for Driven Disks 2-sided
Figure 50 Spare parts Hydraulic hoses for Driven Disks 2-sided
A = Pressure hose
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose
„L“ = length in mm
1
CW700.001300
2
Pressed fitting
2
CW710.004200
B = Return oil hose
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose
„L“ = length in mm
1
CW700.002100
2
Hose stem galv.
2
CW011.600100
3
Clip
2
CW500.034000
4
Union nut
2
CW730.011500
5
Ferrule
2
CW730.011600
Item no.
Specification
Remark
Quantity
Order no.
Hydraulic hoses 2-sided complete
CL917.009000
1
Sticker "Return oil hose"
1
CW002.003400
2
Coupling plug
3
CW720.000200
3
Quick coupling sleeve
1
CW720.003600
4
Dust cover for plug
3
CW720.006000
5
Coupling plug
1
CW730.009000
6
Non-return valve
1
CW730.026000
7
Angular screw connection
4
CW730.073300
8
Cable tie, pink
3
CW830.061000
9
Cable tie, blue
2
CW830.061300
Dust cover for sleeve
not shown
1
CW720.007900
4
2
4
3
Hydraulic motor
Hydraulic motor
1
2
4
A
A
2
2
3
4
4
7
7
7
8
9
9
A
8
7
5
6
8
B
„L“ = length in mm incl. pressed fittings
2
1
2
„L“ = length in mm incl. pressed fittings
5
5
2
1
3
