RADIUS SL PLUS 03.2019 en 48
10.14 Hydraulic hoses Rotary Cultivator 1-sided
(illustration shows CL917.050000 Rotary Cultivator rhs)
A = Pressure hose B = Return oil hose C = Leak oil hose
Figure 52 Spare parts Hydraulic hoses Rotary Cultivator 1-sided
4
B
11
8
6
10
7
14
15
16
12
9
17
A
C
direction of
motor rotation
flow direction
flow direction
Druckseite
1
5
3
13
18
2
