RADIUS SL PLUS 03.2019 en 56
10.19 Hydraulic hoses Mower 1-sided
8
A = Pressure hose
B = Return oil hose
C = Leak oil hose
Figure 57 Spare parts Hydraulic hoses Mower 1-sided
A
B
oil return
C
flow direction
<==
pressure side
flow direction
<==
oil flow direction with mower running!!
==>
oil flow direction with
mower retardation
==>
AA
15
16
1
11
2
3
4
17
18
18
13
10
5
6
6
7
8
9
10
12
14
13
19
AA
