Clemens Technologies CL861.000000 right User Manual

RADIUS SL PLUS 03.2019 en 81
A = Return oil hose RADIUS
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose
„L“ = length in mm
1
CW700.001200
2
Pressed fitting
2
CW710.003800
B = Return oil hose RADIUS
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose
„L“ = length in mm
1
CW700.001700
2
Threaded hose stem
1
CW011.620700
3
Clip 1-eye
2
CW500.034000
Note:
When ordering hydraulic hoses for replacement, measure the length "L" (including pressed
fittings) and indicate in mm (Conversion aid: 1” = 25.4 mm).
Note:
When ordering the hydraulic hoses, pay attention to the different lengths to the right and left
basic unit.
“L“ = length in mm incl. pressed fittings
2
2
“L“ = length in mm incl. pressed fittings
2
3
1
3
