SLEEPVIEW USER MANUAL
35
Appendix B: Technical Specifications
Channel Name
Sampling Rate
Sensor
Respiratory Effort
25
RIP Belt
Body Position
1
Internal 3-axis
accelerometer
Auxiliary
25
Thermistor, IDcheck
or RIP Belt
Airflow, Snore (derived from airflow)
25
Nasal Cannula
Pulse Oximetry, Heart Rate
10
Pulse Oximetry
System Specifications
Storage Humidity:
25% to 95% (non-condensing)
Operating Temperature:
10-40 C
Case Weight (all parts & accessories):
4 lbs
Patient Unit
Dimensions:
3” x 2.6” x 0.7” (7.6 cm x 6.6 cm x 1.8 cm)
Weight:
2 oz (57 g) (approx.) with battery
Number of Channels:
8 channel
Resolution:
12 bits
Power Source:
1 AAA alkaline battery
Battery Life
10 hours continuous use
User Control:
ON/OFF membrane switch
Case Material:
Polycarbonate (20% glass fiber)
Indicators
Power On, Low battery, good signals for auxiliary, nasal cannula,
RIP belt and Pulse oximetry sensors.
