Introduction
1 - 4 System Specifications
1.Introduction
Communication
*Note: The Blue-
tooth and 3.5G Op-
tional Modules
cannot coexist. If
one of these facto-
ry options is includ-
ed in your
purchase option,
then the other is
unavailable.
10M/100Mb Base-T Ethernet LAN
56K MDC Modem V.90 & V.92 Compliant
802.11 b/g Mini-Card USB Wireless LAN Module (Option)
1.3M or 2.0M Pixel USB PC Camera Module (Factory Option)
Bluetooth OR 3.5G Module Options:
*Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option)
OR
*UMTS/HSPDA-based 3.5G Module with Mini-Card Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900 MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Operating
Systems
Supported
Windows XP SP2 Windows Vista 64bit SP1
Home Premium/ Business/ Enterprise/ Ultimate
Power
Management
Supports ACPI 3.0
Supports Resume from Modem Ring
Supports Wake on LAN
Supports Wake on USB
Power Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A or 18.5V, 3.5A (65 Watts)
Battery 4 Cell Smart Lithium-Ion Battery Pack, 14.8V/2.4AH
8 Cell Smart Lithium-Ion Battery Pack, 14.8V/4.4AH (Option)
Environmental
Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions
& Weight
310mm (w) * 233mm (d) * 30-36mm (h)
2.0 kg With 4 Cell Battery and ODD
Feature Specification
UMTS Modes
Note that UMTS
modes CAN NOT
be used in North
America.
To Next Page
