Clevo M730SR - Removing the Optical (CD;DVD) Device

Disassembly
2 - 14 Removing the Optical (CD/DVD) Device
2.Disassembly
Removing the Optical (CD/DVD) Device
1. Turn off the computer, remove the battery (page 2 - 5), and the CPU/RAM bay cover (page 2 - 8).
2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point .
3. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
screw holes should line up.
4. Restart the computer to allow it to automatically detect the new device.
Figure 10
Optical Device
Removal
a. Remove the cover and
locate the screw.
b. Remove the screw and
push the optical device
out off the computer at
point 2 and remove the
optical device.
1
2

3. Optical Device
•1 Screw
2
1
a.
3
b.
