WATER-SOURCE HEAT PUMPS
ATA11U03
Rev.:09/16/13
willbedisplayedintheset-pointlocation.
Toinitiatefactorydefaults,theinstallerthenpressesthe
modebuttonuntilthe10isashing.Theinstallerthen
pressesandholdsthedownbutton.Whilethedown
buttonisheld,the10willcountdownfrom10tozeroat
arateof2countspersecond(5secondstotal).Whenthe
valuereacheszero,alldisplaysegmentsareturnedonfor
vesecondsandthefactorydefaultsarerestored.Ifat
anytimeduringthecountdowntheinstallerreleasesthe
downbutton,thecountdownterminatesandthedisplay
returnstothestartingvalueof10.
Exiting Conguration Mode-Toexittheconguration
mode,pressthefanbutton.
SYSTEM START-UP AND CHECKOUT
Installer Test Mode—Thisthermostathasabuilt-
ininstallertestcapability.Itallowseasyoperationof
equipmentwithoutdelaysorsetpointadjustmentsto
forceheatingorcooling.Toenterinstallertestmode,
pressandholdthefanbuttonfor15seconds(after10
secondsinstallercongurationisentered;acontinuous
15secondsandinstallertestisentered).Atthestartof
installertest,themodeisOff,thefanis“fanauto”and
thesetpointdisplaydisplays“InS.”
NOTE: Unit must be powered up and CXM/DXM
in test mode to disable unit timers or compressor
not energized for more than 5 minutes.
Themodebuttonisusedtochangethesystemoperating
modetotesttheheatingandcoolingequipment.Auto
modeisnotavailableduringinstallertest.
Whenthemodeissettoheat,“H”isdisplayed,heating
isenergizedfor180seconds.Duringtheinstallertest
operation,the“on”iconisdisplayed.
Attheendoftheequipmenttestcyclethemodereturnsto
OFF.
TheLCDdisplaycountsdownthetimeremaining
(inseconds,from180to0)foreachstagewhenthe
equipmentisenergized.SeeFig.5.
Thesameprocedureisrepeatedforthecoolmode.“C”
isdisplayedwhencoolingisactive.
Thetestofaheatingorcoolingcyclecanbeterminated
beforethetimercountsdowntozerobypressingthe
modebutton.
Pressingthefanbuttonalternatesthefanselection
betweenfanautoandfanonandthefanoutputfollows
accordingly. There is no timer associated with the installer
testingofthefanoperation.
Terminating Installer Test—After15minutesofno
buttonpressesbytheinstaller,installertestisterminated.
Pressingtheupbutton,downbutton,orcycling
thermostatpoweratanytimeduringinstallertest
terminatestheinstallertestandreturnsthethermostatto
normaloperation.
Figure 5: Installer Test Mode
Checklist—Thefollowinginstallerchecklistshouldbe
performedaftercompletinginstallation:
1. Runequipmentthroughseveralheatingandcooling
cyclestoensureproperoperation.Tooperatethe
thermostatinitsnormaloperatingmode,consultthe
UserOperatingManual.
2. Iftheequipmentistobeleftinoperation,the
setpointsandoperatingmodemustbeproperly
selected.
3. Putawaytoolsandinstrumentsandcleanupdebris.
4. ReviewandleavethismanualandUserOperating
Manualwithowner.
