Unit Physical Data
Tranquility Console (TRC) Series (50Hz)
Model 09 12 15 18
Compressor (1 Each) Rotary
Factory Charge R410A (oz) [kg] 26 [0.737] 29 [0.822] 33 [0.936] 30 [0.850]
PSC Fan Motor & Blower (3 Speeds)
Fan Motor (hp) [W] 1/20 [37] 1/12 [62] 1/8 [93] 1/8 [93]
Blower Wheel Size (dia x w) -
(in) [mm] - Qty 2
5.25 x 6.25 [133 x 159]
Water Connection Size
O.D. Sweat (in) [mm] 1/2 [12.7] 3/4 [19.1]
Optional IPT Fittings (in) 1/2 3/4
Optional EPT Fittings (in) 1/2 3/4
Condensate Connection Size
I.D. Vinyl Hose (In) [mm] 5/8 [15.9]
Air Coil Size
Dimensions (h x w) - (in) [mm]
8 x 26
[203 x 660]
10 x 26 [254 x 660]
10 x 32
[254 x 813]
Filter Size
Bottom Return (in) [mm] 1 - 10 x 30 x 1 [254 x 762 x 25]
1 - 10 x 36 x 1
[25.4 x 91.4 x 2.5]
Front Return (In) [mm] 1 - 7 x 29.5 x 1/8 [178 x 749 x 3.2]
1 -7 x 35.5 x 1/8
[178 x 902 x 3.2]
Cabinet Size
Bottom Return (Std. 5" [127] Base)
(W x H x D) - (In) [mm]
48 x 26 x 12 [1219 x 660 x 305]
54 x 26 x 12
[1372 x 660 x 305]
Front Return (No Subbase)
(W x H x D) - (In) [mm]
48 x 21 x 12 [1219 x 533 x 305]
54 x 21 x 12
[1372 x 533 x 305]
Cabinet Size
Weight - Operating, (lbs) [kg] 175 [79] 180 [82] 190 [86.2] 220 [99.8]
Weight - Packaged, (lbs) [kg] 185 [83.9] 190 [86] 200 [90.8] 232 [105.2]
All units have rubber grommet compressor mountings and TXV expansion devices.
