ClimateMaster Tranquility TSH 018 - Wiring Diagram - CXM Board & ECM Fan Motor (Single Phase); CXM Controller Fault Codes and Operation; Wiring Diagram Legend and Notes

climatemaster.com
35
Tranquility
®
20 (TE) Series
Rev.: June 5, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Typical Wiring Diagram – Units with CXM Board and ECM Fan Motor
(Single Phase)
