ClimateMaster Tranquility TSH 018 - Wiring Diagram - DXM2 Board & PSC Fan Motor (Three Phase); DXM2 Controller Fault Codes and Operation; Wiring Diagram Legend and Notes

climatemaster.com
37
Tranquility
®
20 (TE) Series
Rev.: June 5, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Typical Wiring Diagram – Units with DXM2 Board and PSC Fan Motor
(Three Phase)
