Clinton HF-15BX - Any Pinhole Alarm (APH)

Model HF-15B High Frequency Spark Tester
HF-15B Instruction Manual – Page 35
– Non Latch Mode
The output will change state for the configured “ABMS” time.
– Latch Mode
The output will change state until it is reset at the front panel or
remotely.
Any Barewire Alarm Time (ABMS)
Set in seconds (.01 – 5.0). If “ABMO” is set to “NLC”, this is the time for
which the output will change state.
Any Pinhole Alarm (APH)
This output will operate in 2 different modes, “NLC”,”LCH”. The Any Pinhole
alarm will respond only to a Pinhole or Multi pinhole fault type. See the “Fault
Typing” section of the manual for more information.
Any Pinhole Alarm Mode (APMO)
– Non Latch Mode
The output will change state for the configured “APMS” time.
– Latch Mode
The output will change state until it is reset at the front panel or
remotely.
Any Pinhole Alarm Time (APMS)
Set in seconds (.01 – 5.0). If “APMO” is set to “NLC”, this is the time for
which the output will change state.
