Specifications
Page 16
5. Electrical Wiring Diagrams
5.1 Indoor unit
Abbreviation Paraphrase
Y/G Yellow-Green Conductor
CAP1 Indoor Fan Capacitor
FAN1 Indoor Fan
L LIVE
N NEUTRAL
TO CCM Comm.Bus Central Controller
T1 Indoor Room Temperature
T2 Coil Temperature of Indoor Heat Exchanger
P3 Super High Speed
P2 High Speed
IB2-XY 35M
