Page 5
2. General Specifications
Indoor Model
IB2-XY 35M
Outdoor Model
MC2-Y 35M
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Power supply (Outdoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Max. Input consumption W 2350 2950 4700
Max. Current A 10 13.5 21.5
Indoor fan motor
Model / ZKFP-46-8-1 ZKFP-124-8-2 ZKFP-124-8-2
Qty / 1 1 1
Input W 45.0 141.0 141.0
Capacitor μF / / /
Speed(Hi/Mi/Lo) r/min 700/580/500 570/500/450 730/670/600
Indoor coil
Number of rows / 2.0 2.0 3.0
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.3 1.4 1.4
Fin type (code) / Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and type mm
ɸ
7,Inner groove tube
ɸ
7,Inner groove tube
ɸ
7,Inner groove tube
Coil length x height x width mm 1300x210x26.74+1360x210x26.74 2010x210x26.74 2010x210x40.11
Number of circuits / 4 10 10
Indoor air flow m
3
/h 617/504/416 1378/1200/1032 1775/1620/1438
Indoor sound pressure level dB(A) 43/39/35 46/43/40 51/49/46
Indoor sound power level dB(A) 57 57 60
Indoor unit
Dimension (W x Dx H)(body) mm 570x570x260
840x840x245 840x840x245
Packing (W x Dx H)(body) mm 662x662x317 900x900x257 900x900x257
Dimension (W x Dx H)(panel) mm 647x647x50 950x950x55 950x950x55
Packing (W x Dx H)(panel) mm 715x715x123 1035x1035x90 1035x1035x90
Net/Gross weight(body) kg 16.2/21.4 24.1/27.9 27.5/31
Net/Gross weight(panel) kg 2.5/4.5 5/8 5/8
Drainage water pipe dia mm OD
ɸ
25mm OD
ɸ
32mm OD
ɸ
32mm
Refrigerant piping Liquid side/ Gas side mm
ɸ
6.35/
ɸ
9.52(1/4”/3/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
Controller Standard Remote control Remote control Remote control
Operation temperature
℃
17-30 17-30 17-30
Room temperature
Cooling
℃
17~32 17~32 17~32
Heating
℃
0~30 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 186/375/429 148/312/342 128/268/294
Compressor
Model / KTN110D42UFZ KTF235D22UMT KTF310D43UMT
Type / ROTARY ROTARY ROTARY
Brand / GMCC
GMCC GMCC
Capacity W 3465 7650 10010
Input W 885 2065 2765
Rated current A 5.95 9.4 5.38
Refrigerant oil/oil charge mL VG74/350 RB74A F/670 VG74/1000
Outdoor Fan motor
Model / ZKFN-40-8-1L-5 ZKFN-50-8-2 ZKFN-120-8-2
Qty / 1 1 1
Input W 40.0 115.0 150.0
Capacitor μF / / /
Speed(Hi) r/min 850/650/450 850 1050
IA2-XY 70M IA2-XY 105M
MC2-Y 70M MC2-Y 105M
