Condenser
Number of rows / 2.0 2.0 2.0
Tube pitch(a)x row pitch(b) mm 21x22 25.4x22 25.4x22
Fin spacing mm 1.2 1.4 1.3
Fin type (code) / Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and type mm
ɸ
7,Inner groove tube
ɸ
9.52,Inner groove
tube
ɸ
9.52,Inner groove tube
Coil length x height x width mm 860x504x44 730x660x44 995x762x44
Number of circuits / 4 4 4
Outdoor side air flow(Hi) m3/h 2000 2700 4000
Outdoor sound pressure level dB(A) 60 58 62
Outdoor sound power level dB(A) 63 62 65
Throttle type Throttle type / EXV+Capillary EXV+Capillary EXV+Capillary
Outdoor unit
Dimension(WxDxH) mm 800x333x554 845x363x702 946x410x810
Packing(WxDxH) mm 920x390x625 965x395x765 1090x500x875
Net/Gross weight kg 34.7/37.5 49.4/52.8 66.8/73.4
Refrigerant
Refrigerant type / R32 R32 R32
GWP / 675 675 675
Refrigerant charge kg 0.87 1.5 2.4
Design pressure MPa 4.3/1.7 4.3/1.7 4.3/1.7
Refrigerant piping
Liquid side/ Gas side mm(inch)
ɸ
6.35/
ɸ
9.52(1/4”/3/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
Max. pipe length m 25 50 65
Max. difference in level m 10 25 30
Ambient temperature
Cooling
℃
-15~50 -15~50 -15~50
Heating
℃
-15~24 -15~24 -15~24
Qty’per 20’ /40’ /40’HQ
Outdoor
unit
108/219/292 102/215/216 44/96/144
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
