Page 7
Indoor Model
Outdoor Model
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Power supply (Outdoor ) V- Ph-Hz 380~415-3-50 380~415-3-50 380~415-3-50
Max. Input consumption W 5600 6200 7500
Max. Current A 10.0 11.2 14
Indoor fan motor
Model / ZKFP-124-8-2 ZKFP-124-8-2 ZKFN-170-8-1
Qty / 1 1 1
Input W 141.0 141.0 232.0
Capacitor μF / / /
Speed(Hi/Mi/Lo) r/min 730/670/600 730/670/600 750/670/600
Indoor coil
Number of rows / 3.0 3.0 3.0
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.4 1.4 1.4
Fin type (code) / Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and type mm
ɸ
7,Inner groove tube
ɸ
7,Inner groove tube
ɸ
7,Inner groove tube
Coil length x height x width mm 2010x210x40.11
1940x252x40.11+2010x252x40.11+
2080x252x40.11
965x252x40.11+965x252x40.11
Number of circuits / 10 12 10
Indoor air flow m3/h 1775/1620/1438 1715/1568/1381 1970/1737/1537
Indoor sound pressure level dB(A) 51/47/41 52/50/49 53/50.5/48
Indoor sound power level dB(A) 59 65 65
Indoor unit
Dimension (W x Dx H)(body) mm 840x840x245 840x840x287 840x840x287
Packing (W x Dx H)(body) mm 900x900x257 900x900x292 900x900x292
Dimension (W x Dx H)(panel) mm 950x950x55 950x950x55 950x950x55
Packing (W x Dx H)(panel) mm 1035x1035x90 1035x1035x90 1035x1035x90
Net/Gross weight(body) kg 27.5/31 29/32.7
29.7/33.4
Net/Gross weight kg 5/8 5/8 5/8
Drainage water pipe dia mm
OD
ɸ
32mm OD
ɸ
32mm OD
ɸ
32mm
Refrigerant piping Liquid side/ Gas side mm
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
Controller Standard Remote control Remote control Remote control
Operation temperature
℃
17-30 17-30 17-30
Room temperature
Cooling
℃
17~32 17~32 17~32
Heating
℃
0~30 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 128/268/294 100/212/238 100/212/238
Compressor
Model / KTF310D43UMT KTQ420D1UMU KTQ420D1UMU
Type / ROTARY ROTARY ROTARY
Brand / GMCC GMCC GMCC
Capacity W 10010 13700 13700
Input W 2765 3700 3700
Rated current A 5.38 7.02 7.02
Refrigerant oil/oil charge mL VG74/1000 VG74/1400 VG74/1400
Outdoor Fan motor
Model / ZKFN-120-8-2 ZKFN-85-8-22 ZKFN-85-8-22-2
Qty / 1 2 2
Input W 150.0 126.0 126.0
Capacitor μF / / /
Speed(Hi) r/min 1050 850 850
Condenser
Number of rows
/ 2.0 1.6 2.0
Tube pitch(a)x row pitch(b) mm 25.4x22 25.4x22 25.4x22
Fin spacing mm 1.3 1.4 1.4
Fin type (code) / Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and type mm
ɸ
9.52,Inner groove tube
ɸ
9.52,Inner groove tube
ɸ
9.52,Inner groove tube
Coil length x height x width mm 995x762x44 990x1270x22+500x1270x22 990x1270x44
Number of circuits / 4 8 8
MC2-Y 105T
IA2-XY 105M
MC2-Y 140T
IA2-XY 140M
MC2-Y 160T
IA2-XY 160M
