Page 8
Outdoor side air flow(Hi) m
3
/h 4000 7500 7500
Outdoor sound pressure level dB(A) 62 66 63.5
Outdoor sound power level dB(A) 64 72 73
Throttle type Throttle type / EXV+Capillary EXV+Capillary EXV+Capillary
Outdoor unit
Dimension(WxDxH) mm 946x410x810 952x415x1333 952x415x1333
Packing(WxDxH) mm 1090x500x875 1095x495x1480 1095x495x1480
Net/Gross weight kg 81.5/87.0 106.7/119.9 111.3/124.3
Refrigerant
Refrigerant type / R32 R32 R32
GWP / 675 675 675
Refrigerant charge kg 2.4 2.8 2.95
Design pressure MPa 4.3/1.7 4.3/1.7 4.3/1.7
Refrigerant piping
Liquid side/ Gas side mm(inch)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
ɸ
9.52/
ɸ
15.9(3/8”/5/8”)
Max. pipe length m 65 65 65
Max. difference in level m 30 30 30
Ambient temperature
Cooling
℃
-15~50 -15~50 -15~50
Heating
℃
-15~24 -15~24 -15~24
Qty’per 20’ /40’ /40’HQ Outdoor unit 44/96/144 22/48/48 22/48/48
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
