4 CKN-XHE2i 7.1-14.2 M06K40A18-00
Humidier cylinder drainage
Cylinder must be drained in these situations:
cleaning of the cylinder
emptying of the cylinder to avoid ice forming
replacement of the cylinder
The manual drainage is carried out by means of selector SA7: see ELECTRIC CONNECTIONS chapter.
Replacement of the cylinder
To remove the cylinder:
completely drain the water
interrupt power supply voltage of humidier by means of the unit isolator
remove the vapour pipe from the cylinder
disconnect the electric connections of the electrodes and remove the pins from the high level electrodes
loosen the ring nut to remove the pipe unions and the lter (when lter is outside the cylinder)
lift the cylinder to remove it
Before mounting it:
the lter body does not require replacing, wash it with water and remount it on the new cylinder, using the new gasket provided with
the latter
check the seal gasket between the cylinder and the drain unit
remount the cylinder repeating the operations in reverse order
