5 - ELECTRICAL CONNECTIONS
HID-T2 / T3 THERMOSTAT
5.8 MINI-NETWORK - MAX 9 ELFORoom
2
* 120 network termination resistance - customer care
5.9 ELFOSystem
1. Bus RS485
2. ELFOControl
3
EVO
3. SPHERA
4. ELFOFRESH
2
/ ELFOFRESH EVO
5. Zone with 2 ELFOROOM
2
with keypad and HID-T2 thermostat controls both terminals
6. Zone with 1 ELFOROOM
2
with keypad and HID-T2 thermostat that controls the terminal
7. ELFOROOM
2
with keypad and HID-T3 thermostat that controls both terminals
8. ELFOROOM
2
with built-in thermostat
65
