CLIVET WiSAN-YME 1 S 2.1 Service Manual

LAYOUT OF COMPONENTS
6
2. Layout of components
2.1 Sizes 2.1 - 3.1
1
2
3
4
5
6 7 8
9
10
11
1213
14
15
N° Component
1 Pressure sensor
2 Electronic expansion valve
3 High pressure switch
4 Water flow switch
5 Air relief valve
6 Source exchanger: finned coil
7 Fan
8 4-way valve
9 Main board
10 Water side heat exchanger
11 Water circulator
12 Low pressure switch
13 Compressor inverter
14 Gas-suction separator
15 Water pressure relief valve
