CLIVET WSAN-EE 21 - Page 47

M02R40C8-00 29/07/08 page 47
Size 131-151
"G"
1711
1476
78
150 1225 325
174 505
2
7
3
5
5
8
10
9
684
1
6
4
5
670
1700
(11)
500
150
100
(11)
(11)
1
OP
W1
W4
W2
W3
150
325
2063020
N M
120
12
12
7
1
6
3
The units require minimum clearances for operation and maintenance. The following sketch describes the minimum clearances to be considered. In the event of multiple units, the functional clearances
must be doubled.
(1) COMPRESSOR
(2) ELECTRICAL PANEL
(3) INTERNAL EXCHANGER
(4) EXTERNAL EXCHANGER
(5) HELICAL FANS
(6) PUMP
(7) EXPANSION VESSEL
(8) WATER OUTLET (STANDARD UNIT)
(9) WATER INLET (STANDARD UNIT)
(10) POWER INPUT
(11) CLEARANCE ACCESS RECOMMENDED
(12) LIFTING HOLES
("G") BARYCENTRE
SIZE 131 151
M
mm
703 706
N
mm
517 514
O
mm
292 292
P
mm
378 378
Length
mm
1710 1710
Depth
mm
684 684
Height
mm
1477 1477
W1
kg
94 97
W2
kg
56 57
W3
kg
73 75
W4
kg
44 44
Operating weight
kg
268 273
Shipping weight
kg
275 280
