M08P40G16-00 WSH-XEE2 10.2-120.2 23
6.12 Water reset
Menu accessible only after having entered the password.
Access reserved only to specically trained personnel.
The parameter modication can cause irreversible damages.
The water reset correction aects the setpoint dened by the Climate curve TExt (actual setpoint).
The setpoint is shown at status S0052: ActualUtSetp
Only if P0003: En WaterReset ≠ 0
Path: Main menu / Unit parameters / Water reset cong
Step Display Action Menu/Variable Keys Notes
1 Press 3 sec.
2 Password Set Password
3 Press
4 Main menu Select Unit parameters
5 Unit parameters Select Water reset
6 Water reset Select Parameter
7Set
8 Conrm
9 Press 3 sec.
10 Select Local connections
Path: Main Menu / Unit parameters / Water reset
Parameters Short description Description
P0616 MaxCWRC Maximum correction to be applied to the setpoint Cooling
P0617 SWRMaxC Value of the WR control signal corresponding to the correction of the set Cool equal to P0616
P0618 SWRMinC Value of the WR control signal corresponding to the correction of the set COOL equal to 0
P0615 MaxCWRH Maximum correction to be applied to the setpoint Heating
P0619 SWRMaxH Value of the WR control signal corresponding to the correction of the set Heating equal to P0615
P0620 SWRMinH Value of the WR control signal corresponding to the correction of the set Heating equal to 0
P0616 / P0618: Cooling
P0615, P0619, P0620: Heating
