CLIVET WSH-XEE2 Series User Manual

M08P40G16-00 WSH-XEE2 10.2-120.2 39
8.10 Compressor supply line shut-o valve
A
A. Supply line shut-o valve
Do not remove the seal
Remove only if authorized by the manufacturer.
Please contact the maker for informations.
8.11 crankcase heather
Check:
•
closure
•
Operation
8.12 Copeland scroll compressor
Compressor may stop Pumping With Motor Running
Turn Off And Wait Until Cool
May need More Than 1 Hour To Reset
Advanced Scroll Temperature Protection

CLIVET WSH-XEE2 Series Specifications

General

Series	WSH-XEE2
Category	Chiller
Power Supply	400V/3Ph/50Hz
Refrigerant	R134a
Sound Pressure Level	68 - 77 dB(A) (depending on the model)
Operating Temperature Range (Cooling)	15 to 48 °C (ambient)
Operating Temperature Range (Heating)	-10 to 35 °C (ambient)
IP Rating	IP54
