If there is more than one disabled event from the same zone present, then the MORE keys can
be pressed to manually switch between the individual device information with each device
occupying a full four lines of information.
If disabled events are present from more than one zone then the top level zone screen will
indicate as such. For example:
DISABLED (Zones) Total: 02
01 Z005 First Floor Offices 12:57
02 Z001 Ground Floor Offices 13:01
================== DISABLED ========
By pressing the VIEW POINTS key the user can then manually scroll through the individual
device information for all disabled events from all zones with disablements through using the
MORE keys. If more than two zones have disablements then the MORE LEDs will illuminate.
The screen will display the first disablement on the second line and the newest zone with
disablements on the third line. The second line will be used to scroll through all of the zones
with disablements when the MORE keys are operated.
4.6 Print archive log
There are reports that can be produced on the text display or the printer if the panel is
configured with one.
1. Go to the top level operator menu as described in section 4.1
OPERATOR
1.Time & date
2. Reports to display 4. Lamptest
3. Reports to printer 5. Keypad test
2. Press 2 for reports to display or 3 for reports to printer
(Assumes 3 was pressed)
OPERATOR: REPORTS TO PRINTER
1.Archives 4.Future
2.Point status 5.Future
3.Future 6.Stop printer
