Electric Chain
®
Operating, Maintenance & Parts Manual
Rated Loads 1/8 To 3 Tonnes
125 Kg To 3000 Kg
00001996 (REV AB) 627NH
Follow all instructions and warning for
inspecting, maintaining and operating
this hoist.
The use of any hoist presents some risk of personal injury or
property damage. That risk is greatly increased if proper
instructions and warnings are not followed. Before using this
hoist, each operator should become thoroughly familiar with all
warnings, instructions, and recommendations in this manual.
Retain this manual for future reference and use.
Forward this manual to the hoist operator.
Failure to operate the equipment as directed in the manual
may cause injury.
Before using the hoist, fill in the information below.
Refer to the hoist identification plate.
Model Number
Serial Number
Purchase Date
Voltage
Rated Load

Table of Contents

Questions and Answers

  • A
    Amanda ThomasSep 7, 2025
    What to do if CM LODESTAR NH Chain Hoists will not operate at slow speed?
    • M
      Melanie CraigSep 7, 2025
      If your CM Chain Hoists will not operate at slow speed in either direction, consider these possibilities: * There may be an open circuit due to an open or shorted motor winding, a loose or broken wire, or a speed selecting contactor stuck in the opposite speed mode. Replace the motor, repair the wire, and/or replace the speed selecting contactor. * There could be a phase failure. Check for electrical continuity and repair or replace defective part.
  • B
    Brandon WagnerNov 21, 2025
    Why CM LODESTAR NH motor overheats?
    • A
      adkinsalexNov 21, 2025
      Several factors can cause a CM Chain Hoists motor to overheat: * Low voltage can cause the motor to overheat. Correct the low voltage condition. * Excessive load can strain the motor. Reduce the load to the hoist's capacity limit. * Extreme external heat, especially above 40°C (104°F), requires limiting the frequency of hoist operation or improving ventilation and shielding. * Frequent starting or reversing can overheat the motor. Avoid excessive inching, jogging, or plugging to prolong motor and contactor life and reduce brake wear. * Phase failure or unbalanced current in the phases can lead to overheating. Check for electrical continuity and repair or replace the defective part. * A dragging brake can cause the motor to work harder. Check the brake adjustment. * For 115-1...
  • L
    Laurie RodriguezNov 19, 2025
    What to do if CM LODESTAR NH Chain Hoists hook does not respond to the control station?
    • D
      Diana VegaNov 20, 2025
      If the hook on your CM Chain Hoists does not respond to the control station, there are several potential causes: * There may be no voltage at the hoist, a switch may be open, or a fuse may be blown. In this case, close the switch, replace the fuse, or reset the breaker. * There could be a phase failure. Check for electrical continuity and repair or replace the defective part. * The upper or lower limit switch may have opened the control circuit. Press the other control to see if the hook responds. Adjust the limit switches. * There might be an open control circuit due to a winding issue, loose connection, or mechanical binding. Check electrical continuity and repair or replace any defective parts. * The voltage or frequency could be incorrect. Use the voltage and frequency indic...
  • S
    Sarah ChavezSep 18, 2025
    What to do if CM LODESTAR NH Chain Hoists hook moves correctly at one speed but wrong at another?
    • R
      Ryan LopezSep 18, 2025
      If the hook on your CM Chain Hoists moves in the proper direction at one speed but in the wrong direction at the other speed, it is likely due to: * Phase reversal: Wiring reconnected improperly. Interchange two leads of motor winding that is out of phase at the speed selecting relay.
  • J
    Joseph PatelSep 16, 2025
    What to do if CM LODESTAR NH Chain Hoists hook will not lower at fast speed?
    • M
      Mrs. Christina DownsSep 16, 2025
      If the hook on your CM Chain Hoists will not lower at fast speed, check for: * Phase Failure. Check for electrical continuity and repair or replace defective part. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • C
    Carla ShawSep 14, 2025
    What to do if CM LODESTAR NH hook will not raise at fast speed?
    • C
      Colleen FletcherSep 14, 2025
      If the hook on your CM Chain Hoists will not raise at fast speed, check for: * Excessive load. Reduce loading to the capacity limit of hoist as indicated on the identification plate. * Phase Failure. Check for electrical continuity and repair or replace defective part. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • J
    jillian46Sep 12, 2025
    What to do if CM Chain Hoists hook will not lower at slow speed?
    • M
      Mark BaileySep 12, 2025
      If the hook on your CM Chain Hoists will not lower at slow speed, check for: * Phase Failure. Check for electrical continuity and repair or replace defective part. * Open Circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • S
    Stacy McconnellSep 12, 2025
    What to do if CM Chain Hoists hook will not raise at slow speed?
    • R
      robertsjosephSep 12, 2025
      If the hook on your CM Chain Hoists will not raise at slow speed, check for: * Excessive load. Reduce loading to the capacity limit of hoist as indicated on the identification plate. * Phase Failure. Check for electrical continuity and repair or replace defective part. * Open Circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • T
    Tyrone SmithSep 9, 2025
    What to do if CM Chain Hoists will not operate at fast speed?
    • L
      Laura FoxSep 9, 2025
      If your CM Chain Hoists will not operate at fast speed in either direction, check the following: * There may be an open circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * There could be an open speed selecting circuit due to a winding issue, loose connection, mechanical binding, or control station contact problems. Replace the speed selector, repair the connection, replace the contactor or control station. * There could be a phase failure. Check for electrical continuity and repair or replace defective part.
  • G
    gary18Aug 25, 2025
    What to do if CM LODESTAR NH Chain Hoists hook moves in wrong direction?
    • J
      Jesse KellyAug 25, 2025
      If the hook on your CM Chain Hoists moves in the wrong direction, here are a few things to check: * For single-phase units, wiring connections may be reversed at the control station or terminal board. Compare the connections to the wiring diagram. * Also for single-phase units, the motor reversing switch might fail to effect dynamic braking at the time of reversal. Check the connections to the switch and replace any damaged or faulty capacitor. * For three-phase units, there may be a phase reversal.
