Before installing hoist, fi ll in the information below.
Model Number
Serial No.
Pur
chase Date
V
oltage
Rated Load
RATED LOADS 1/8 TO 3 TONNES
125 KG TO 3000 KG
Follow all instructions and warning for inspecting,
maintaining and operating this hoist.
The use of any hoist presents some risk of personal injury
or property damage. That risk is greatly increased if proper
instructions and warnings are not followed. Before using
this hoist, each operator should become thoroughly familiar
with all warnings, instructions and recommendations in this
manual. Retain this manual for future reference and use.
Forward this manual to operator. Failure to operate equipment
as directed in manual may cause injury.
ELECTRIC CHAIN HOIST
OPERATING, MAINTENANCE
& PARTS MANUAL
P/N: 00001996 (REV AC) 627NH October 2014
Distributed by Ergonomic Partners
Sales@ErgonomicPartners.com
www.ErgonomicPartners.com
Tel: (314) 884-8884

Table of Contents

Other manuals for CM Lodestar RR

Preview: Installation Operating & Maintenance Manual
Installation Operating & Maintenance Manual24 pages

Questions and Answers

  • M
    Michael MartinSep 7, 2025
    What to do if CM Lodestar RR Chain Hoists will not operate at slow speed?
    • E
      Erica StrongSep 7, 2025
      If your CM Chain Hoists will not operate at slow speed in either direction, consider these possibilities: * There may be an open circuit due to an open or shorted motor winding, a loose or broken wire, or a speed selecting contactor stuck in the opposite speed mode. Replace the motor, repair the wire, and/or replace the speed selecting contactor. * There could be a phase failure. Check for electrical continuity and repair or replace defective part.
  • M
    Melissa PalmerNov 21, 2025
    Why CM Chain Hoists motor overheats?
    • J
      josephjohnNov 21, 2025
      Several factors can cause a CM Chain Hoists motor to overheat: * Low voltage can cause the motor to overheat. Correct the low voltage condition. * Excessive load can strain the motor. Reduce the load to the hoist's capacity limit. * Extreme external heat, especially above 40°C (104°F), requires limiting the frequency of hoist operation or improving ventilation and shielding. * Frequent starting or reversing can overheat the motor. Avoid excessive inching, jogging, or plugging to prolong motor and contactor life and reduce brake wear. * Phase failure or unbalanced current in the phases can lead to overheating. Check for electrical continuity and repair or replace the defective part. * A dragging brake can cause the motor to work harder. Check the brake adjustment. * For 115-1...
  • P
    Paul TorresNov 19, 2025
    What to do if CM Lodestar RR hook does not respond to the control station?
    • D
      Dr. Tony GomezNov 19, 2025
      If the hook on your CM Chain Hoists does not respond to the control station, there are several potential causes: * There may be no voltage at the hoist, a switch may be open, or a fuse may be blown. In this case, close the switch, replace the fuse, or reset the breaker. * There could be a phase failure. Check for electrical continuity and repair or replace the defective part. * The upper or lower limit switch may have opened the control circuit. Press the other control to see if the hook responds. Adjust the limit switches. * There might be an open control circuit due to a winding issue, loose connection, or mechanical binding. Check electrical continuity and repair or replace any defective parts. * The voltage or frequency could be incorrect. Use the voltage and frequency indic...
  • C
    Christopher PerrySep 18, 2025
    What to do if CM Lodestar RR hook moves correctly at one speed but wrong at another?
    • J
      Jaime PerezSep 18, 2025
      If the hook on your CM Chain Hoists moves in the proper direction at one speed but in the wrong direction at the other speed, it is likely due to: * Phase reversal: Wiring reconnected improperly. Interchange two leads of motor winding that is out of phase at the speed selecting relay.
  • D
    danielle37Sep 16, 2025
    What to do if CM Chain Hoists hook will not lower at fast speed?
    • K
      kimberly23Sep 16, 2025
      If the hook on your CM Chain Hoists will not lower at fast speed, check for: * Phase Failure. Check for electrical continuity and repair or replace defective part. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • N
    nancy02Sep 14, 2025
    What to do if CM Lodestar RR Chain Hoists hook will not raise at fast speed?
    • S
      Sean SmithSep 14, 2025
      If the hook on your CM Chain Hoists will not raise at fast speed, check for: * Excessive load. Reduce loading to the capacity limit of hoist as indicated on the identification plate. * Phase Failure. Check for electrical continuity and repair or replace defective part. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • M
    Michael TuckerSep 12, 2025
    What to do if CM Lodestar RR Chain Hoists hook will not lower at slow speed?
    • D
      Debra GardnerSep 12, 2025
      If the hook on your CM Chain Hoists will not lower at slow speed, check for: * Phase Failure. Check for electrical continuity and repair or replace defective part. * Open Circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • P
    Paula JohnsonSep 12, 2025
    What to do if CM Lodestar RR hook will not raise at slow speed?
    • S
      Sandra SmithSep 12, 2025
      If the hook on your CM Chain Hoists will not raise at slow speed, check for: * Excessive load. Reduce loading to the capacity limit of hoist as indicated on the identification plate. * Phase Failure. Check for electrical continuity and repair or replace defective part. * Open Circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * Brake not releasing. Check electrical continutiy and connections. Check that correct coil has been installed. The coil for three phase dual voltage unit operates at 230 volts when the hoist is connected for either 230 volt or 460 volt operation. Check brake adjustment.
  • R
    Rodney DavisSep 9, 2025
    What to do if CM Chain Hoists will not operate at fast speed?
    • C
      castrosophiaSep 9, 2025
      If your CM Chain Hoists will not operate at fast speed in either direction, check the following: * There may be an open circuit. Open or shorted motor winding, loose or broken wire in circuit, speed selecting contactor stuck in opposite speed mode. Replace motor, repair wire and/or replace speed selecting contactor. * There could be an open speed selecting circuit due to a winding issue, loose connection, mechanical binding, or control station contact problems. Replace the speed selector, repair the connection, replace the contactor or control station. * There could be a phase failure. Check for electrical continuity and repair or replace defective part.
  • E
    Elizabeth MorenoAug 25, 2025
    What to do if CM Lodestar RR Chain Hoists hook moves in wrong direction?
    • R
      Roger BrooksAug 25, 2025
      If the hook on your CM Chain Hoists moves in the wrong direction, here are a few things to check: * For single-phase units, wiring connections may be reversed at the control station or terminal board. Compare the connections to the wiring diagram. * Also for single-phase units, the motor reversing switch might fail to effect dynamic braking at the time of reversal. Check the connections to the switch and replace any damaged or faulty capacitor. * For three-phase units, there may be a phase reversal.

Summary

Installation

Installing the Suspension

Detailed steps for attaching suspension assemblies for single, double, and triple reeved units.

Attaching Load Chain

Procedure for connecting the load chain to the hoist, including checks for twists.

Power Supply and Electrical Connections

Operating Instructions

Safe Operating Instructions and Procedures

Essential do's and don'ts for safe hoist operation, covering load handling and environment.

Inspection

Preventative Maintenance

Program to prolong hoist life, maintain reliability, and ensure continued safe use.

Inspecting the Load Chain

Maintenance

Hoist Lubrication

Brake Adjustments

Procedure for adjusting the DC electric brake assembly for correct air gap.

Limit Switch Adjustments

Step-by-step instructions for setting the upper and lower limit switches.

Troubleshooting

Hook fails to stop at either or both ends of travel.

Reference Wiring Diagrams

CM Lodestar RR Specifications

General IconGeneral
Operation TypeElectric
Safety Factor5:1
Load Capacity1/4 to 3 Ton
Power Supply115 VAC, 1-Phase
ChainAlloy steel, heat-treated, load chain
BrakeMechanical Brake
Chain TypeAlloy Steel
StandardASME B30.16
