C.M.C. n.v. - Airmaster R1 installation guide – base unit – V1.1 – MANY0317A.00
Page 8 of 41
3. Technical specifications
3.1 General technical data
Processor 16bit ST ST10R272
Flash EPROM 256 Kbytes (512 Kbytes maximum)
Non Volatile RAM 256 Kbytes (512 Kbytes maximum)
I/O processor AduC814BRU (8051 compatible)
A to D Resolution 12bit (1/4096)
D to A Resolution 12bit (1/4096)
RTC Device Real Time Calendar Clock (option)
Supply input 24Vac (+-20%) 50VA
or 24Vdc (20 – 36 Vdc) 40W
Analogue Inputs 4 standard 12 maximum
Digital Inputs 8 standard 16 maximum
Analogue Outputs 2 standard - -
Relay Outputs 6 standard 10 maximum
(consult CMC for combination availability)
Construction steel casing, zinc anti-corrosion
Mounting 35mm Rail, DIN 46277-3
Dimensions 115mm x 166mm x 88mm
Connections PCB mounted, Phoenix compatible
Conformity
3.2 Temperature range
Operating temperature 0°C to +55°C
Storage temperature -25°C to +75°C
Relative humidity at 40°C(non condensing) <95%
According to:
Operating tests at -10°C and +65°C
IEC 68-2-2 B Dry heat, 4 days
IEC 68-2-14 Nb Cyclic, 6hrs/cycle, 5 days
IEC 68-2-3 Ca Damp heat steady, 40°C, tbd R.H., 10 days
IEC 68-2-30 Db Damp heat cyclic, +50°C, variant 1, 2 cycles
IEC 68-2-1 A Cold, 4 days
Storage tests at -25°C and +75°C
IEC 68-2-1 A Cold 6 days
IEC 68-2-14 Na Change of temperature, 3hrs/temp, 2 cycles
IEC 68-2-2 B Dry heat 6 days
US
C
