CMOSTEK CMT2300A - Sensitivity VS. Voltage

CMT2300A
Rev 1.0 | Page12/46
www.cmostek.com
Test Condition: Freq = 868MHz, Fdev = 10KHz, BR = 10Kbps
1.12.3 Sensitivity VS. Voltage
Test Condition: FSK, DEV = 10KHz, BR = 10Kbps
7.0
7.3
7.5
7.8
8.0
8.3
8.5
8.8
9.0
9.3
9.5
-40
25
85
Current Consumption(mA)
Temperature(℃)
Rx Current vs. Volt-Temp
3.3V
1.8V
3.6V
-117.5
-117.0
-116.5
-116.0
-115.5
-115.0
-114.5
-114.0
-113.5
-113.0
1.8
2.1
2.4
2.8
3.0
3.3
3.6
Sensitivity(dBm)
Supply Voltage(V)
Sensitivity vs. Voltage
434MHz
868MHz
