CMOSTEK CMT2300A - CMT2300 A Electrical Characteristics; Recommended Operation Condition; Absolute Maximum Rating

CMT2300A
Rev 1.0 | Page4/46
www.cmostek.com
1. Electrical Characteristics
V
DD
= 3.3 V, T
OP
= 25 °C, F
RF
= 433.92 MHz, the sensitivity is measured by receiving a PN9 coded data and matching the
impedance to 50Ωunder the 0.1%BER standard.Unless otherwise stated, all results are tested on theCMT2300A-EM evaluation
board.
1.1 Recommended OperationCondition
Table 1. Recommended operation condition
Parameter
Symbol
Condition
Min.
Typ.
Max.
Unit
Power voltage
V
DD
1.8
3.6
V
Operating temperature
T
OP
-40
85
℃
Power voltage slope
1
mV/us
1.2 Absolute Maximum Rating
Table 2. Absolute Maximum Ratings
[1]
Parameter
Symbol
Conditions
Min
Max
Unit
Supply Voltage
V
DD
-0.3
3.6
V
Interface Voltage
V
IN
-0.3
V
DD
+0.3
V
Junction Temperature
T
J
-40
125
℃
Storage Temperature
T
STG
-50
150
℃
Soldering Temperature
T
SDR
Lasts at least 30 seconds
255
℃
ESD Rating
[2]
Human Body Model (HBM)
-2
2
kV
Latch-up Current
@ 85 ℃
-100
100
mA
Notes:
[1]. Stresses above those listed as “absolute maximum ratings” may cause permanent damage to the device. This is a stress
rating only and functional operation of the device under these conditions is not implied. Exposure to maximum rating
conditions for extended periods may affect device reliability.
[2].
Caution! ESD sensitive device. Precaution should be used when handling the device in order
to prevent permanent damage.
